Jandy | VSPHP270DV2AS | VS PlusHP Variable Speed Pump with SpeedSet Controller | 2.7 HP, 115/230V
Jandy | VSPHP270DV2AS | VS PlusHP Variable Speed Pump with SpeedSet Controller | 2.7 HP, 115/230V
The Jandy VSPHP270DV2AS VS PlusHP is a 2.7 HP variable speed pool pump with a factory-installed SpeedSet Controller. This dual-voltage pump operates on 115V or 230V power and is designed for residential pool and spa circulation systems requiring flexible speed control and automation-ready operation.
━━━━━━━━━━━━━━━━━━
Key Features
• Genuine Jandy VS PlusHP variable speed pump with SpeedSet Controller included
• 2.7 total horsepower motor designed for pool and spa circulation applications
• Auto-sensing dual-voltage operation supports 115V or 230V electrical service
• Variable speed design operates from 600 RPM to 3450 RPM for adjustable flow control
• Includes 2" x 2.5" unions for installation and service accessibility
• Factory-installed SpeedSet Controller supports local pump programming and operation
• Two programmable auxiliary relays can support compatible external equipment control
• RS-485 quick connect port supports communication with compatible Jandy control systems
• Zero Clearance TEFC motor design allows installation in tighter equipment pad layouts
• Large strainer basket helps support efficient flow and routine maintenance access
━━━━━━━━━━━━━━━━━━
Product Overview
The Jandy VSPHP270DV2AS VS PlusHP Variable Speed Pump is designed for residential pool and spa systems requiring a 2.7 HP variable speed pump with integrated local control. The included SpeedSet Controller provides convenient pump programming and operation, while the auto-sensing dual-voltage motor supports both 115V and 230V installations.
This pump is built for feature-rich pool systems, including applications with pool and spa combinations, solar heating, in-floor systems, sheer descents, and water features when properly sized. With 2" x 2.5" unions, RS-485 connectivity, dry contact relay control, and programmable auxiliary relay capability, it provides a flexible circulation solution for compatible Jandy equipment layouts. Professional installation is recommended to verify plumbing, electrical, flow, and control requirements.
Original: $2,600.00
-65%$2,600.00
$910.00Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
The Jandy VSPHP270DV2AS VS PlusHP is a 2.7 HP variable speed pool pump with a factory-installed SpeedSet Controller. This dual-voltage pump operates on 115V or 230V power and is designed for residential pool and spa circulation systems requiring flexible speed control and automation-ready operation.
━━━━━━━━━━━━━━━━━━
Key Features
• Genuine Jandy VS PlusHP variable speed pump with SpeedSet Controller included
• 2.7 total horsepower motor designed for pool and spa circulation applications
• Auto-sensing dual-voltage operation supports 115V or 230V electrical service
• Variable speed design operates from 600 RPM to 3450 RPM for adjustable flow control
• Includes 2" x 2.5" unions for installation and service accessibility
• Factory-installed SpeedSet Controller supports local pump programming and operation
• Two programmable auxiliary relays can support compatible external equipment control
• RS-485 quick connect port supports communication with compatible Jandy control systems
• Zero Clearance TEFC motor design allows installation in tighter equipment pad layouts
• Large strainer basket helps support efficient flow and routine maintenance access
━━━━━━━━━━━━━━━━━━
Product Overview
The Jandy VSPHP270DV2AS VS PlusHP Variable Speed Pump is designed for residential pool and spa systems requiring a 2.7 HP variable speed pump with integrated local control. The included SpeedSet Controller provides convenient pump programming and operation, while the auto-sensing dual-voltage motor supports both 115V and 230V installations.
This pump is built for feature-rich pool systems, including applications with pool and spa combinations, solar heating, in-floor systems, sheer descents, and water features when properly sized. With 2" x 2.5" unions, RS-485 connectivity, dry contact relay control, and programmable auxiliary relay capability, it provides a flexible circulation solution for compatible Jandy equipment layouts. Professional installation is recommended to verify plumbing, electrical, flow, and control requirements.
